OP200GPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC303559
Category:
Operational Amplifier, OP Amp IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES OP200GPZ Operational Amplifier, Dual, 2 Amplifier, 500kHz, 0.15V/µs, ± 3V to ± 18V, DIP, 8Pins
Stock Locations:
Availability:
548 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 13.53

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OP200GPZ is a monolithic dual Operational Amplifier offers OP77 type precision performance. The OP200 combines precision performance with the space and cost savings offered by a dual amplifier. The OP200 features an extremely low input offset voltage of less than 75µV with a drift below 0.5µV/°C, guaranteed over the full military temperature range. On-chip Zener zap trimming is used to achieve the extremely low input offset voltage of the OP200 and eliminates the need for offset pulling. Power consumption of the OP200 is low, with each amplifier drawing less than 725µA of supply current. The total current drawn by the dual OP200 is less than one-half that of a single OP07, yet the OP200 offers significant improvements over this industry-standard op amp. The voltage noise density of the OP200, 11nV/√Hz at 1kHz, is half that of most competitive devices.
Low offset and low power
75µV Maximum low input offset voltage
725µA Maximum low supply current (per amplifier)
5000V/mV Minimum high open-loop gain
2nA Maximum low input bias current
11nV/√Hz at 1kHz Low noise voltage density
10nF Typical Stable with large capacitive loads
120dB CMRR
1.8µV/V PSRR

Show

OP200GPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	15.0 V
Operating Voltage	3V ~ 18V
Supply Current	570 µA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Power Dissipation	66 mW
Common Mode Rejection Ratio	130 dB
Bandwidth	500 kHz
Slew Rate	150 mV/μs
Gain Bandwidth Product	500 kHz
Input Impedance	125 GΩ
Input Offset Voltage	80 µV
Input Bias Current	100 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	0.5 MHz
Minimum CMRR Range	110 dB
Supply Voltage (Max)	18 V
Supply Voltage (Min)	3 V
	Show
Size-Length	9.27 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2017/07/07
