Image is for your reference only,please check specifications for details

OPA2172ID - TI
Manufacturer:
TI
ManyChip's Part#:
MC43727536
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS OPA2172ID Operational Amplifier, Dual, 2 Amplifier, 10MHz, 10V/µs, 4.5V to 36V, ± 2.25V to ± 18V, SOIC
Stock Locations:
Availability:
238 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.88

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OPA2172ID is a dual low noise Operational Amplifier with rail-to-rail output. The single-supply operational amplifier offers low offset, drift and quiescent current. This device also offers wide bandwidth, fast slew rate and high output current drive capability. The dual version has identical specifications for maximum design flexibility. Unlike most op amps, which is specified at only one supply voltage, the OPAx172 family is specified from +4.5 to +36V. Input signals beyond the supply rails do not cause phase reversal. The input can operate 100mV below the negative rail and within 2V of the top rail during normal operation.
EMI and RFI filtered inputs
Input range includes the negative supply
Input range operates to positive supply
Rail-to-rail output
±0.2mV Low offset voltage
±0.3µV/°C Low offset drift
±8pA Low input bias current
1.6mA/amplifier Low quiescent current
7nV/√Hz Low noise
120dB High common-mode rejection
Green product and no Sb/Br

Show

OPA2172ID Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	1.6 mA
Number of Circuits	2 Circuit
Number of Positions	8 Position
Common Mode Rejection Ratio	90 dB
Input Offset Drift	300 nV/K
Bandwidth	10 MHz
Slew Rate	10.0 V/μs
Gain Bandwidth Product	10 MHz
Input Offset Voltage	1 mV
Input Bias Current	3 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Minimum CMRR Range	90 dB
Supply Voltage	4.5V ~ 36V
	Show
Size-Length	3.05 mm
Size-Width	1.75 mm
Size-Height	1.45 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
