Image is for your reference only,please check specifications for details

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OPA453FAKTWT is a single Operational Amplifier with high-voltage (80V) and high-current capabilities (50mA). The OPA452 is unity-gain stable and has a gain bandwidth product of 1.8MHz, whereas the OPA453 is optimized for gains greater than 5 and has a 7.5MHz bandwidth. It is internally protected against over-temperature conditions and current overloads. Power supplies in the range of ±10 to ±40V can be used. Unlike most other power op amp, the OPA453 has ensured specifications over the entire power-supply range. These laser-trimmed, monolithic integrated circuits provide excellent low-level accuracy along with wide output swing. Special design considerations assure that the product is easy to use and free from phase inversion problems often found in other amplifiers.
Fully protected - Thermal shutdown and output current-limited
50mA Continuous high output load drive
1V to rail Wide output voltage swing
5µV/°C Typical offset drift
94dB Typical CMRR
Green product and no Sb/Br

Show

OPA453FAKTWT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	TO-263-7
Supply Current	5.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	7 Position
Common Mode Rejection Ratio	86 dB
Input Offset Drift	5.00 µV/K
Bandwidth	7.5 MHz
Slew Rate	23.0 V/μs
Gain Bandwidth Product	7.5 MHz
Input Offset Voltage	1 mV
Input Bias Current	7 PA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	7.5 MHz
Minimum CMRR Range	86 dB
Supply Voltage (Max)	40 V
Supply Voltage (Min)	10 V
	Show
Size-Length	10.41 mm
Size-Width	10.987 mm
Size-Height	4.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
