Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 4 Pin |
Voltage Rating (DC) | 30.0 V |
Input Voltage (DC) | 1.60V (max) |
Output Voltage | 30.0 V, 30.0 V (max) |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Number of Positions | 4 Position |
Input Current | 20.0 mA |
Peak Wavelength | 890 nm |
Power Dissipation | 50.0 mW |
Isolation Voltage | 10 kVDC |
Input Current (Min) | 40 mA |
Maximum Forward Voltage (Max) | 1.6 V |
Show | |
Material | Plastic |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
