Description

General description PNP low VCE(sat )Breakthrough In Small Signal (BISS) transistor in a SOT23 (TO-236AB)small Surface-Mounted Device (SMD) plastic package. Features Low collector-emitter saturation voltage VCEsat High collector current capability IC and ICM High collector current gain (hFE) at high IC High efﬁciency due to less heat generation Applications General-purpose switching and muting LCD backlighting Supply line switching circuits Battery-driven equipment (mobile phones, video cameras and handheld devices)

Show

PBSS5140T Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-236
Polarity	PNP
Power Dissipation	300 mW
Breakdown Voltage (Collector to Emitter)	40 V
Continuous Collector Current	1A
	Show
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
