Description

The PESD5V0V1BB is a very low capacitance bidirectional ESD Protection Diode designed to protect one signal line from the damage caused by ESD and other transients.
Bidirectional ESD protection of one line
11pF Very low diode capacitance (Cd)
45W Maximum peak pulse power (PPP)
<1nA Ultra low leakage current (IRM)
ESD protection up to 30kV

Show

PESD5V0V1BB Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SOD-523
Number of Positions	2 Position
Power Dissipation	45 W
Clamping Voltage	12.5 V
Test Current	5 mA
Peak Pulse Power	45 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
	Show
Size-Length	1.25 mm
Size-Width	0.85 mm
Size-Height	0.65 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
