- SMLV56RGB1W1 - ROHM Semiconductor
-
Manufacturer:ROHM Semiconductor
-
ManyChip's Part#:MC15434972
-
Category:Based LED
-
Package:3528
-
Datasheet:Datasheet 3D Model
-
Description:SMLV56 Series Red/Green/Blue 1411 Diffused 700/1200/400mcd 2.1/3.3/3.3V SMT LED
-
Stock Locations:
-
Availability:0 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- ROHM Chip LED SML-V56 Series LEDs
- The SML-V56 series of LEDs, from ROHM Semiconductor, are in the 3528 (1411) package. The SML-V56 a high brightness tri-colour LEDs. Their low profile package and improved colour mixture is made possible by a flat frame structure.
- Package size: 3.5 x 2.8 x 0.6 mm
- Operating temperature: -40 to 85°C
SMLV56RGB1W1 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 6 Pin |
| Case/Package | 3528 |
| Power Rating | 400 mW |
| Number of Positions | 6 Position |
| Wavelength | 624 nm, 527 nm, 470 nm |
| Viewing Angle | 120° |
| Power Dissipation | 400 W |
| Test Current | 20 mA |
| Forward Current | 5 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 400 mW |
| Show | |
| Size-Width | 2.8 mm |
| Size-Height | 0.70 mm |
| Color | Red, Green, Blue (RGB) |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
