Description
- The SN74CBTLV1G125DBVR is a single FET Bus Switch features a single high-speed line switch. The switch is disabled when the OE\ input is high. This device is fully specified for partial-power-down applications using Ioff. The Ioff feature ensures that damaging current will not backflow through the device when it is powered down. The device has isolation during power off. To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pull-up resistor, the minimum value of the resistor is determined by the current-sinking capability of the driver.
- Rail-to-rail switching on data I/O ports
- 5R Switch connection between two ports
- Ioff Supports partial-power-down mode operation
- Green product and no Sb/Br
SN74CBTLV1G125DBVR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SOT-23-5 |
| Supply Voltage (DC) | 2.30V (min) |
| Contacts Type | SPST |
| Supply Current | 250 mA |
| Number of Channels | 1 Channel |
| Number of Positions | 5 Position |
| Number of Bits | 1 Bit |
| Propagation Delay Max (tpd) | 250 ps |
| Polarity | Non-Inverting |
| Number of Gates | 1 Gate |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 2.3V ~ 3.6V |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 2.3 V |
| Show | |
| Size-Length | 3.05 mm |
| Size-Width | 1.75 mm |
| Size-Height | 1.3 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2018/01/15 |
| ECCN Code | EAR99 |
