Image is for your reference only,please check specifications for details

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

SPW24N60C3 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Voltage Rating (DC)	650 V
Current Rating	24.3 A
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.14 Ω
Polarity	N-Channel
Power Dissipation	240 W
Threshold Voltage	3 V
Input Capacitance	3.00 nF
Gate Charge	135 nC
Drain to Source Voltage (Vds)	650 V
Continuous Drain Current (Ids)	24.3 A
Rise Time	21 ns
Input Capacitance (Ciss)	3000pF @25V(Vds)
Input Power (Max)	240 W
Fall Time	14 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	240W (Tc)
	Show
Size-Length	16.03 mm
Size-Width	5.16 mm
Size-Height	21.1 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR
