STD5NM50 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	DPAK-252
Polarity	N-CH
Drain to Source Voltage (Vds)	500 V
Continuous Drain Current (Ids)	7.5A
Rise Time	8 ns
Input Capacitance (Ciss)	415pF @25V(Vds)
Fall Time	6 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	100000 mW
	Show
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
