STP4NK80ZFP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Channels	1 Channel
Polarity	N-CH
Power Dissipation	25 W
Threshold Voltage	4.5 V
Input Capacitance	575 pF
Drain to Source Voltage (Vds)	800 V
Continuous Drain Current (Ids)	3A
Rise Time	12 ns
Input Capacitance (Ciss)	575pF @25V(Vds)
Input Power (Max)	25 W
Fall Time	32 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	25000 mW
	Show
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	9.3 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Rail, Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
