Description

The STPS20M100SFP is a Power Schottky Rectifier featuring high current capability and high frequency operation. This single Schottky rectifier is suited for high frequency switch mode power supply. This device is intended to be used in notebook, game station and desktop adaptors, providing in these applications a good efficiency at both low and high load.
Avalanche rated
Low forward voltage drop current
2000V Insulating voltage
12pF Package capacitance

Show

STPS20M100SFP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Positions	3 Position
Forward Voltage	850mV @20A
Thermal Resistance	4℃/W (RθJC)
Forward Current	20 A
Max Forward Surge Current (Ifsm)	530 A
Maximum Forward Voltage (Max)	850 mV
Forward Current (Max)	20 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	150℃ (Max)
	Show
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99
