STTH1R04U - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC13333304
Category:
TVS Diode
Package:
DO-214AA
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS STTH1R04U Fast / Ultrafast Diode, 400V, 1A, Single, 1.5V, 30ns, 30A
Stock Locations:
Availability:
29 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.04

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The STTH1R04U is an Ultra-fast Recovery Diode especially suited for switching mode base drive and transistor circuits. Packaged in axial and surface mount packages, this device is intended for use in low voltage, high frequency inverters, free-wheeling and polarity protection.
Planar Pt doping technology
Negligible switching losses
Low forward and reverse recovery times
High junction temperature

Show

STTH1R04U Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	DO-214AA
Forward Voltage	1.5V @1A
Thermal Resistance	25℃/W (RθJL)
Reverse recovery time	30 ns
Forward Current	1 A
Max Forward Surge Current (Ifsm)	30 A
Maximum Forward Voltage (Max)	1.5 V
Forward Current (Max)	1 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
	Show
Size-Length	4.6 mm
Size-Width	3.95 mm
Size-Height	2.45 mm
Operating Temperature	-65℃ ~ 175℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
