Image is for your reference only,please check specifications for details
- STTH803D - ST Microelectronics
-
Manufacturer:ST Microelectronics
-
ManyChip's Part#:MC1618941
-
Category:TVS Diode
-
Package:TO-220-2
-
Datasheet:Datasheet 3D Model
-
Description:Diode Switching 300V 8A 2Pin(2+Tab) TO-220AC Tube
-
Stock Locations:
-
Availability:288 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.88
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- DESCRIPTION
- Single Fast Recovery Epitaxial Diode suited for Switch Mode Power Supply and high frequency DC/DC converters.
- Packaged in TO-220AC or D2PAK this device is especially intended for secondary rectification.
- FEATURES AND BENEFITS
- ■ COMBINES HIGHEST RECOVERY AND REVERSE VOLTAGE PERFORMANCE
- ■ ULTRA-FAST, SOFT AND NOISE-FREE RECOVERY
STTH803D Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 2 Pin |
| Case/Package | TO-220-2 |
| Voltage Rating (DC) | 300 V |
| Current Rating | 8.00 A |
| Output Current | ≤8.00 A |
| Forward Voltage | 1.25V @8A |
| Polarity | Standard |
| Reverse recovery time | 35 ns |
| Forward Current | 8000 mA |
| Maximum Forward Voltage (Max) | 1.25V @8A |
| Forward Current (Max) | 8 A |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -65 ℃ |
| Junction Temperature | 175℃ (Max) |
| Show | |
| Operating Temperature | -65℃ ~ 175℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Compliant with Exemption |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
