Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- **SUW Series**
- Rated Input: DC4.5 - 9V, DC9 - 18V, DC18 - 36V, DC36 - 76V, Rated Output Wattage: 1.5 - 10W
- **Features**
- * SMD mounting type and through-hole mounting type
- * High efficiency
- * Built-in overcurrent protection circuits
- * Built-in remote ON/OFF (SU/SUC 3, 6, 10)
- * High reliability: not built-in aluminum and tantalum electrolytic capacitor
SUCW100515B Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 7 Pin |
| Case/Package | SMD |
| Output Current | 0.35 A |
| Output Power | 10.5 W |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 4.5V ~ 9V |
| Show | |
| Size-Length | 1.58 in |
| Size-Width | 0.87 in |
| Size-Height | 0.28 in |
| Operating Temperature | -40℃ ~ 85℃ |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
