Image is for your reference only,please check specifications for details

TJA1040T - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC83912764
Package:
SOIC8
Datasheet:
Datasheet 3D Model
Description:
CAN 1MBd Standby 5V Automotive 8Pin SO
Stock Locations:
Availability:
10,514 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.58

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Overview
The TJA1040 is the interface between the Controller Area Network (CAN) protocol controller and the physical bus. It is primarily intended for high speed applications, up to 1 MBaud, in passenger cars. The device provides differential transmit capability to the bus and differential receive capability to the CAN controller.
The TJA1040 is the next step up from the TJA1050 high speed CAN transceiver. Being pin compatible and offering the same excellent EMC performance, the TJA1040 also features:
* An ideal passive behaviour when supply voltage is off
* A very low-current standby mode with remote wake-up capability via the bus.
This makes the TJA1040 an excellent choice in nodes which can be in power-down or standby mode in partially powered networks.
MoreLess
## Features
* Fully compatible with the ISO 11898 standard
* High speed (up to 1 MBaud)
* Very low-current standby mode with remote wake-up capability via the bus
* Very low ElectroMagnetic Emission (EME)
* Differential receiver with high common-mode range for ElectroMagnetic Immunity (EMI)
* Transceiver in unpowered state disengages from the bus (zero load)
* Input levels compatible with 3.3 V and 5 V devices
* Voltage source for stabilizing the recessive bus level if split termination is used (further improvement of EME)
* At least 110 nodes can be connected
* Transmit Data (TXD) dominant time-out function
* Bus pins protected against transients in automotive environments
* Bus pins and pin SPLIT short-circuit proof to battery and ground
* Thermally protected.
## Features

Show

TJA1040T Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	8 Pin
Case/Package	SOIC8
	Show
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
