TLE4242G - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC15618980
Category:
LED Driver, LED Display Driver
Package:
TO-263-8
Datasheet:
Datasheet 3D Model
Description:
LED Driver 3Segment 5V/9V/12V/15V/18V/24V Automotive 8Pin(7+Tab) TO-263
Stock Locations:
Availability:
2,512 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.9

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

**Functional Description**
The TLE 4242 G is an integrated adjustable constant current source driving loads up to 500 mA. The output current level can be adjusted via an external resistor. The IC is designed to supply high power LEDs (e.g. Osram Dragon LA W57B) under the severe conditions of automotive applications resulting in constant brightness and extended LED lifetime. It is provided in the surface mounted PG-TO263-7-1 package. Protection circuits prevent damage to the device in case of overload, short circuit, reverse polarity and
overheat. The connected LEDs are protected against reverse polarity as well as excess voltages up to 45 V.
**Features**
• Adjustable constant current up to 500 mA (±5%)
• Wide input voltage range up to 42 V
• Low drop voltage
• Open load detection
• Overtemperature protection
• Short circuit proof
• Reverse polarity proof
• Wide temperature range: -40 °C to 150 °C
• Green Product (RoHS compliant)
• AEC Qualified

Show

TLE4242G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	TO-263-8
Number of Outputs	1 Output
Input Voltage (DC)	4.50V ~ 42.0V
Output Voltage	40 V
Output Current	500 mA
Input Voltage (Max)	42 V
Input Voltage (Min)	4.5 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 42V
Input Voltage	4.5V ~ 42V
	Show
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Not Recommended for New Design
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
ECCN Code	EAR99
