Description
- Programmable Controllers
- AC / DC−Input Module
- Solid State Relay
- The TOSHIBA TLP504A and TLP504A−2 consists of a photo−transistor optically coupled to a gallium arsenide infrared emitting diode.
- The TLP504A offers two isolated channels in an eight lead plastic DIP package, while the TLP504A−2 provides four isolated channels in a sixteen plastic DIP package.
- • Collector−emitter voltage: 55 V (min.)
- • Current transfer ratio: 50% (min.) Rank GB: 100% (min.)
- • Isolation voltage: 2500 Vrms (min.)
- • UL recognized: UL1577,File no. E67349
TLP504A Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 8 Pin |
| Case/Package | PDIP |
| Input Voltage (DC) | 1.15 V |
| Output Voltage | ≤55.0 V |
| Number of Circuits | 2 Circuit |
| Number of Channels | 2 Channel |
| Rise Time | 2.00 µs |
| Isolation Voltage | 2500 Vrms |
| Show | |
| Product Lifecycle Status | Not Recommended |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
