Description

The TPD8S009DSMR is an 8-channel ESD Protection TVS Diode Array for HDMI/DisplayPort. It is rated to dissipate contact ESD strikes at the maximum level specified in the IEC 61000-4-2 international standard (level 4), with ±8kV contact discharge ESD protection. The low capacitance (0.8pF) of this device, coupled with the excellent matching between differential signal pairs enables this device to provide transient voltage suppression circuit protection for high-speed differential data rates (3dB bandwidth >4GHz).
IEC 61000-4-2 level 4 ESD protection ±8kV contact discharge
IEC 61000-4-5 Surge protection 2.5A (8/20µs)
10nA Low leakage current
Supports high-speed differential data rates (3dB bandwidth >4GHz)
-40 to 85°C Operating temperature range

Show

TPD8S009DSMR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	15 Pin
Case/Package	SMD-15
Supply Voltage (DC)	-300 mV (min)
Operating Voltage	5.5 V
Capacitance	0.8 pF
Breakdown Voltage	9 V
Number of Channels	8 Channel
Number of Positions	15 Position
Power Dissipation	25 W
Clamping Voltage	20 V
Test Current	1 mA
Peak Pulse Power	25 W
Min Breakdown Voltage	9 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	6.6 mm
Size-Width	2.6 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
