Description
- Drive a high voltage and high current line with a transistor a certain way with this TPS2814PWR power driver manufactured by Texas Instruments. This device has a maximum propagation delay time of 50 ns and a maximum power dissipation of 520 mW. Its maximum power dissipation is 520 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This gate driver has an operating temperature range of -40 °C to 125 °C. This device has a minimum operating supply voltage of 4 V and a maximum of 14 V.
TPS2814PWR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | TSSOP-8 |
| Supply Voltage (DC) | 14.0V (max) |
| Rise/Fall Time | 14ns, 15ns |
| Number of Outputs | 2 Output |
| Supply Current | 5.00 mA |
| Power Dissipation | 0.52 W |
| Rise Time | 35 ns |
| Fall Time | 35 ns |
| Fall Time (Max) | 35 ns |
| Fall Time (Max) | 35 ns |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 520 mW |
| Supply Voltage | 4V ~ 14V |
| Show | |
| Operating Temperature | -40℃ ~ 125℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
