- TPS65130RGER - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC2948040
-
Category:DC to DC Converter
-
Package:VQFN-24
-
Datasheet:Datasheet 3D Model
-
Description:Conv DC-DC 2.7V to 5.5V Inv/Step Up Dual-Out -15V to -2V/3.2V to 15V 0.8A 24Pin VQFN EP T/R
-
Stock Locations:
-
Availability:250 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.94
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- DESCRIPTION
- The TPS65130/1 is dual-output dc-dc converter generating a positive output voltage up to 15 V and a negative output voltage down to -15 V with output currents in a 200-mA range in typical applications, depending on input voltage to output voltage ratio. With a total efficiency up to 85%, the device is ideal for portable battery-powered equipment.
- FEATURES
- • Dual Adjustable Output Voltages Up to +15 V and Down to –15 V
- • 800-mA Typical Switch Current Limit at Boost and Inverter Main Switches at TPS65130
- • 2-A Typical Switch Current Limit at Boost and Inverter Main Switches at TPS65131
- • Up to 89% Efficiency at Positive Output Voltage Rail
- • Up to 81% Efficiency at Negative Output Voltage Rail
- • Power-Save Mode for High Efficiency at Low Load Currents
- • Independent Enable Inputs for Power Up and Power Down Sequencing
- • Control Output for External PFET to Support Completely Disconnecting the Battery
- • 2.7-V to 5.5-V Input Voltage Range
- • Minimum 1.25-MHz Fixed Frequency PWM Operation
- • Thermal Shutdown
- • Overvoltage Protection on Both Outputs
- • 1-µA Shutdown Current
- • Small 4 mm x 4 mm QFN-24 Package (RGE)
- APPLICATIONS
- • Small to Medium Size OLED Displays
- • (TFT) LCD and CCD Bias Supply
- • PDAs, Pocket PCs, Smartphones
- • Digital Cameras
- • Camcorders
TPS65130RGER Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 24 Pin |
| Case/Package | VQFN-24 |
| Number of Outputs | 2 Output |
| Output Voltage | 15.0 V |
| Output Current | 800 mA |
| Number of Positions | 24 Position |
| Quiescent Current | 500 µA |
| Number of Regulated Outputs | 2 Output |
| Switching Frequency | 1.38 MHz |
| Input Voltage (Max) | 5.5 V |
| Input Voltage (Min) | 2.7 V |
| Output Current (Max) | 0.8 A |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 2.7 V |
| Input Voltage | 2.5V ~ 5.5V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
| HK STC License | NLR |
