Image is for your reference only,please check specifications for details
- L6374FP - ST Microelectronics
-
Manufacturer:ST Microelectronics
-
ManyChip's Part#:MC12293000
-
Category:Interface IC, Interface Controller
-
Package:SOIC-20
-
Datasheet:Datasheet 3D Model
-
Description:**QUAD DRIVER 35V 0.1A SO20 SMD **
-
Stock Locations:
-
Availability:58 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 8.88
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Description
- The L6374 is especially designed to be used as a line driver in industrial control systems based on the 24 V signal levels (IEC 61131, 24VDC).
- Features
- ■ Four independent line drivers with 100 mA up to 35 V outputs
- ■ Input signals between - 7 V and + 35 V, with pre-setting threshold
- ■ Push-pull outputs with three state control and true zero current between Vs and ground
- ■ Current limiting on each output effective in the full "ground to Vs" output voltage range
- ■ Output voltage clamp to Vs and to ground
- ■ Overtemperature and undervoltage protections
- ■ Diagnostic for overtemperature, undervoltage and overcurrent
- ■ Pre-setting delay for overcurrent diagnostic
- ■ High speed operation: up to 300 kHz with 35 V swing
L6374FP Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | SOIC-20 |
| Supply Voltage (DC) | 35.0V (max) |
| Number of Outputs | 4 Output |
| Output Current | 100 mA |
| Supply Current | 5 mA |
| Number of Channels | 4 Channel |
| Number of Positions | 20 Position |
| Output Current (Max) | 100 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -25 ℃ |
| Supply Voltage | 10.8V ~ 35V |
| Supply Voltage (Max) | 35 V |
| Supply Voltage (Min) | 10.8 V |
| Show | |
| Size-Length | 10 mm |
| Size-Width | 4 mm |
| Size-Height | 1.65 mm |
| Operating Temperature | -25℃ ~ 125℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
