TPS74801DRCR - TI
Manufacturer:
TI
ManyChip's Part#:
MC179596
Category:
Voltage Regulator
Package:
VSON-10
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS TPS74801DRCR LDO Voltage Regulator, Adjustable, 800mV to 5.5V in, 60mV drop, 800mV to 3.6V/1.5A out, SON-10
Stock Locations:
Availability:
2,584 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.52

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPS748 low-dropout (LDO) linear regulator provides an easy-to-use robust power management solution for a wide variety of applications. User-programmable soft-start minimizes stress on the input power source by reducing capacitive inrush current on start-up. The soft-start is monotonic and well-suited for powering many different types of processors and ASICs. The enable input and power good output allow easy sequencing with external regulators. This complete flexibility permits the user to configure a solution that meets the sequencing requirements of FPGAs, DSPs, and other applications with special start-up requirements.
A precision reference and error amplifier deliver 2% accuracy over load, line, temperature, and process. The device is stable with any type of capacitor greater than or equal to 2.2 µF, and is fully specified for TJ = –40°C to 125°C. The TPS748 is offered in a small, 3-mm × 3-mm, VSON-10 package, yielding a highly compact, total solution size. The device is also available in a 5 × 5 QFN-20 package for compatibility with the TPS744.

Show

TPS74801DRCR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	VSON-10
Number of Outputs	1 Output
Input Voltage (DC)	5.50V (max)
Output Voltage	0.8V ~ 3.6V
Output Current	1.5 A
Number of Positions	10 Position
Power Dissipation	1920 W
Quiescent Current	1.00 mA
Output Capacitor Type	Ceramic
voltage rating	0.06V @1500mA
Number of Regulated Outputs	1 Output
Input Voltage (Max)	5.5 V
Input Voltage (Min)	0.8 V
Output Voltage (Max)	3.6 V
Output Voltage (Min)	800 mV
Output Current (Max)	1.5 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	2 %
Number of Output Channels	1 Channel
Input Voltage	0.8V ~ 5.5V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
