TPS75215QPWP - TI
Manufacturer:
TI
ManyChip's Part#:
MC40550330
Category:
Voltage Regulator
Package:
HTSSOP-20
Datasheet:
Datasheet 3D Model
Description:
Single Channel LDO Single Output LDO, 2A, Fixed(1.5V), SVS, Fast Transient Response LDO Regulator Pos 1.5V 2A 20Pin HTSSOP EP Tube
Stock Locations:
Availability:
231 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.76

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPS75215QPWP is a 1.5V fixed output low-dropout (LDO) Linear Regulator with integrated power-ON reset. Quiescent current is 75µA at full load and drops down to 1µA when the device is disabled. These devices are designed to have fast transient response for larger load current changes. Because the PMOS device behaves as a low-value resistor, the dropout voltage is very low and is directly proportional to the output current. Additionally, because the PMOS pass element is a voltage-driven device, the quiescent current is very low and independent of output loading (typically 75µA over the full range of output current, 1mA to 2A). These two key specifications yield a significant improvement in operating life for battery-powered systems. The device is enabled when EN is connected to a low-level input voltage. This LDO family also features a sleep mode, applying a TTL high signal to EN (enable) shuts down the regulator, reducing the quiescent current to less than 1µA at TJ = +25°C.
Open drain power-ON reset with 100ms delay
Fast transient response
2% Tolerance over specified conditions
Thermal shutdown protection
Green product and no Sb/Br

Show

TPS75215QPWP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	HTSSOP-20
Power Rating	7.2 W
Number of Outputs	1 Output
Input Voltage (DC)	5.00V (max)
Output Voltage	1.5 V
Output Current	2 A
Supply Current	125 µA
Number of Positions	20 Position
Power Dissipation	7.2 W
Quiescent Current	0.075 mA
Output Capacitor Type	Tantalum
voltage rating	210 mV
Number of Regulated Outputs	1 Output
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Voltage (Min)	1.5 V
Output Current (Max)	2 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	7200 mW
Accuracy	±2 %
Input Voltage	2.7V ~ 5.5V
	Show
Size-Length	6.5 mm
Size-Width	4.4 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
