Image is for your reference only,please check specifications for details
- TUNS100F12 - Cosel
-
Manufacturer:Cosel
-
ManyChip's Part#:MC72340807
-
Category:Switching Power Supply, Power Switch
-
Package:DIP-7
-
Datasheet:Datasheet 3D Model
-
Description:AC-DC Power Modules 100W 12V 8.4A AC-DC Power Supply
-
Stock Locations:
-
Availability:6 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 154.98
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- **Features:**
- * High Cosel Quality — Company Wide Failure Rate of 29 ppm
- * AC-DC Power Module with Power Factor Correction
- * Universal Input — 85-264 VAC
- * Operate with Up to 100°C Baseplate Temperature
- * Over-Current Protection
- * Over-Voltage Protection
- * Over-Temperature Protection
- * Full Function Model Is Available(TUFS300/TUFS500)
- * UL, C-UL, TÜV and CE Approvals
- * Five-Year Warranty
- * CE and RoHS Compliant
TUNS100F12 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 9 Pin |
| Case/Package | DIP-7 |
| Power Rating | 100.8 W |
| Number of Outputs | 1 Output |
| Output Voltage | 12 VDC |
| Output Current | 8.4 A |
| Output Power | 100.8 W |
| Isolation Voltage | 3 kV |
| Input Voltage (AC Max) | 264 V |
| Input Voltage (AC Min) | 85 V |
| Output Current (Max) | 8.4 A |
| Input Current (Min) | 1.3 A |
| Operating Temperature (Max) | 100 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 85VAC ~ 264VAC |
| Show | |
| Size-Length | 61 mm |
| Size-Width | 12.7 mm |
| Size-Height | 12.7 mm |
| Weight | 120 g |
| Operating Temperature | -40℃ ~ 100℃ |
| Product Lifecycle Status | Active |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
