- TVP5150AM1IPBSR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC476544
-
Category:CODEC
-
Package:TQFP-32
-
Datasheet:Datasheet 3D Model
-
Description:Ultralow Power NTSC/PAL/SECAM Video Decoder w/Robust Sync Detector 32-TQFP -40℃ to 85℃
-
Stock Locations:
-
Availability:414 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 3.76
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Description
- The TVP5150AM1 device is an ultralow-power NTSC/PAL/SECAM video decoder. Available in a space-saving 48-terminal PBGA package or a 32-terminal TQFP package, the TVP5150AM1 decoder converts NTSC, PAL, and SECAM video signals to 8-bit ITU-R BT.656 format. Discrete syncs are also available. The optimized architecture of the TVP5150AM1 decoder allows for ultralow power consumption.
- Features
- • Accepts NTSC (J, M, 4.43), PAL (B, D, G, H, I, M, N, Nc), and SECAM (B, D, G, K, K1, L) Video
- • Supports ITU-R BT.601 Standard Sampling
- • High-Speed 9-Bit Analog-to-Digital Converter (ADC)
- • Two Composite Inputs or One S-Video Input
- • Fully Differential CMOS Analog Preprocessing
- Channels With Clamping and Automatic Gain
- Control (AGC) for Best Signal-to-Noise (S/N) Performance
- • Ultralow Power Consumption
- • 48-Terminal PBGA Package (ZQC) or 32-Terminal TQFP Package (PBS)
- • Power-Down Mode: <1 mW
- • Brightness, Contrast, Saturation, Hue, and Sharpness Control Through I2C
- • Complementary 4-Line (3-H Delay) Adaptive Comb Filters for Both Cross-Luminance and Cross-Chrominance Noise Reduction
- • Patented Architecture for Locking to Weak, Noisy, or Unstable Signals
- • Single 14.31818-MHz Crystal for All Standards
- • Internal Phase-Locked Loop (PLL) for Line-Locked Clock and Sampling
- • Subcarrier Genlock Output for Synchronizing Color Subcarrier of External Encoder
- • 3.3-V Digital I/O Supply Voltage Range
- • Standard Programmable Video Output Formats
- – ITU-R BT.656, 8-Bit 4:2:2 With Embedded Syncs
- – 8-Bit 4:2:2 With Discrete Syncs
- • Macrovision™ Copy Protection Detection
- • Advanced Programmable Video Output Formats
- – 2× Oversampled Raw Vertical Blanking Interval (VBI) Data During Active Video
- – Sliced VBI Data During Horizontal Blanking or Active Video
- • VBI Modes Supported
- – Teletext (NABTS, WST)
- – Closed-Caption Decode With FIFO and Extended Data Services (XDS)
- – Wide Screen Signaling, Video Program System, CGMS-A, Vertical Interval Time Code
- – Gemstar 1x/2x Electronic Program Guide Compatible Mode
- – Custom Configuration Mode That Allows User to Program Slice Engine for Unique VBI Data Signals
- • Power-On Reset
- • Industrial Temperature Range
- (TVP5150AM1I): –40°C to 85°C
- • Qualified for Automotive Applications
- (AEC-Q100 Rev G – TVP5150AM1IPBSQ1, TVP5150AM1IPBSRQ)
TVP5150AM1IPBSR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 32 Pin |
| Case/Package | TQFP-32 |
| Supply Voltage (DC) | 3.30 V |
| Number of Channels | 2 Channel |
| Number of Positions | 32 Position |
| Number of Bits | 9 Bit |
| Power Dissipation | 150 mW |
| Sample Rate | 30.0 MHz |
| Number of ADCs | 1 ADC |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 150 mW |
| Number of Input Channels | 2 Channel |
| Supply Voltage | 1.8 V |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Not Recommended for New Designs |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
