UAA2016PG - ON Semiconductor
Manufacturer:
ON Semiconductor
ManyChip's Part#:
MC3761463
Category:
Power Monitor
Package:
PDIP-8
Datasheet:
Datasheet 3D Model
Description:
UAA2016PG AC-DC Driver; Zero Voltage Switching Controllers; 8Pin PDIP
Stock Locations:
Availability:
240 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.59

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The UAA2016PG is a Zero Voltage Switch Power Controller designed to drive triacs which allows RFI-free power regulation of resistive loads. Operating directly on the AC power line, its main application is the precision regulation of electrical heating systems such as panel heaters or irons. A built-in digital saw-tooth waveform permits proportional temperature regulation action over a ±1°C band around the set point. For energy savings there is a programmable temperature reduction function and for security a sensor failsafe inhibits output pulses when the sensor connection is broken. Preset temperature application is also possible.
Direct AC line operation
Proportional regulation of temperature over a 1°C band
Programmable temperature reduction
Preset temperature
Sensor failsafe
Adjustable hysteresis
Low external component count
Pb-free device

Show

UAA2016PG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	-10.0 V (max), -8.00 V (min)
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Output Voltage	5.5 V
Output Current	0.13 A
Supply Current	900 µA
Number of Channels	1 Channel
Number of Positions	8 Position
Input Current	1.5 mA
Output Current (Max)	150 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Supply Voltage	8.10 VDC
	Show
Size-Length	10.16 mm
Size-Width	6.6 mm
Size-Height	3.44 mm
Operating Temperature	-20℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
