Description
- Use the UCC27424DGNR power driver from Texas Instruments to turn on and off your high-power transistors! This device has a maximum propagation delay time of 150 ns and a maximum power dissipation of 3000 mW. Its maximum power dissipation is 3000 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This device has a minimum operating supply voltage of 4 V and a maximum of 15 V. This gate driver has an operating temperature range of -40 °C to 105 °C.
UCC27424DGNR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | PowerPad-MSOP-8 |
| Supply Voltage (DC) | 4.00V (min) |
| Power Rating | 3 W |
| Rise/Fall Time | 20ns, 15ns |
| Number of Outputs | 2 Output |
| Output Voltage | 330 mV |
| Output Current | 4 A |
| Number of Channels | 2 Channel |
| Power Dissipation | 3000 mW |
| Rise Time | 20 ns |
| Fall Time | 15 ns |
| Fall Time (Max) | 40 ns |
| Fall Time (Max) | 40 ns |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 3000 mW |
| Supply Voltage | 4V ~ 15V |
| Supply Voltage (Max) | 15 V |
| Supply Voltage (Min) | 4 V |
| Show | |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
