UCC28880D - TI
Manufacturer:
TI
ManyChip's Part#:
MC18369514
Category:
AC to DC Converter, AC/DC Power Module
Package:
SOIC-7
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS UCC28880D AC-DC Converter IC, Buck, Buck-Boost, Flyback, Primary-Side Regulation, 30VAC - 700VAC, SOIC-7
Stock Locations:
Availability:
311 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.93

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The UCC28880D is a High Voltage Switcher for non-isolated AC/DC conversion, integrates the controller and a 700V power MOSFET into one monolithic device. The device also integrates a high-voltage current source, enabling start up and operation directly from the rectified mains voltage. The low quiescent current of the device enables excellent efficiency. With the UCC28880D the most common converter topologies, such as buck, buck-boost and flyback can be built using a minimum number of external components. The UCC28880D incorporates a soft-start feature for controlled start up of the power stage which minimizes the stress on the power-stage components.
Integrated power MOSFET (switch) rated to 700V drain-to-source voltage
Integrated high-voltage current source for internal low-voltage supply generation
Soft-start
Self-biased switcher (start-up and operation directly from rectified mains voltage)
Supports buck, buck-boost and flyback topologies
<100µA Device quiescent current
Robust performance with inductor current runaway prevention
Current limit, overload, output short-circuit and over-temperature protection
Green product and no Sb/Br
Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

UCC28880D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	SOIC-7
Number of Outputs	1 Output
Output Voltage	3.3 V
Output Current	100 mA
Breakdown Voltage	700 V
Number of Positions	7 Position
Quiescent Current	60.0 µA
Output Power	4 W
Switching Frequency	62 kHz
Topology	Buck
Duty Cycle	55 %
Input Voltage (AC Max)	700 v
Input Voltage (AC Min)	30 v
Maximum Duty Cycle	55 %
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
	Show
Operating Temperature	-40℃ ~ 105℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
