VN820 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	Pentawatt-5
Supply Voltage (DC)	36.0V (max)
Number of Outputs	1 Output
Output Current	9 A
Supply Current	25.0 mA
Number of Channels	1 Channel
Drain to Source Resistance (on) (Rds)	80.0 mΩ
Power Dissipation	65800 mW
Output Current (Max)	9 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	40 ℃
Supply Voltage	5.5.36 VDC
Supply Voltage (Min)	5.5 V
	Show
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99
