Description

DESCRIPTION
The VNP20N07FI, VNB20N07 and VNV20N07 are monolithic devices made using STMicroelectronics VlPower M0 Technology, intended for replacement of standard power MOSFETS in DC to 50 KHz applications. Built-in thermal shut-down, linear current limitation and overvoltage clamp protect the chip in harsh enviroments. Fault feedback can be detected by monitoring the voltage at the input pin.
■ LINEAR CURRENT LIMITATION
■ THERMAL SHUT DOWN
■ SHORT CIRCUIT PROTECTION
■ INTEGRATED CLAMP
■ LOW CURRENT DRAWN FROM INPUT PIN
■ DIAGNOSTIC FEEDBACK THROUGH INPUT PIN
■ ESD PROTECTION
■ DIRECT ACCESS TO THE GATE OF THE POWER MOSFET (ANALOG DRIVING)
■ COMPATIBLE WITH STANDARD POWER MOSFET

Show

VNV20N07 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	12 Pin
Case/Package	PowerSO-10
Number of Outputs	1 Output
Drain to Source Resistance (on) (Rds)	50.0 mΩ
Power Dissipation	83.0 W
Breakdown Voltage (Drain to Source)	70.0 V
Continuous Drain Current (Ids)	20.0 A
Output Current (Max)	14 A
	Show
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99
