Description

The ZB5AA4 is a 22mm red flush Pushbutton Head for use with the XB5 series momentary non-illuminated pushbutton switch. The head features plastic bezel and spring return operation.
Round shape signalling unit head
-25 to 70°C Ambient temperature range

Show

ZB5AA4 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Actuator Type	Button
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-25 ℃
	Show
Size-Length	28 mm
Size-Width	29 mm
Size-Height	29 mm
Color	Red
Material	Plastic
Housing Material	Plastic
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
