Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | - |
Pin Pitch | 5 mm |
Number of Contacts | 2 Contact |
Wire Gauge | 14AWG ~ 30AWG |
Current Rating | 13.5 A |
Number of Rows | 1 Row |
Number of Circuits | 2 Circuit |
Flammability Rating | UL 94 V-0 |
Number of Positions | 2 Position |
Current Rating (Max) | 13.5 A |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -40 ℃ |
Voltage Rating (Max) | 400 V |
Voltage Rating | 400 V |
Operating Voltage (Max) | 400 V |
Show | |
Size-Length | 8.1 mm |
Size-Width | 5 mm |
Size-Height | 10 mm |
Housing Color | Green |
Color | Green |
Contact Material | Copper Alloy |
Material | Polyamide (PA) |
Insulation Material | Nylon |
Operating Temperature | -40℃ ~ 100℃ |
Housing Material | Nylon |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536904000 |
ECCN Code | EAR99 |
