Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Pin Pitch | 3.81 mm |
Number of Contacts | 6 Contact |
Contact Plating | Tin |
Voltage Rating (DC) | 640 mV |
Current Rating | 8 A |
Number of Rows | 1 Row |
Flammability Rating | UL 94 V-0 |
Number of Positions | 6 Position |
Mounting Angle | 90.0 ° |
Current Rating (Max) | 8 A |
Voltage Rating | 300 V |
Maximum Contact Resistance (Max) | 1.5 mΩ |
Show | |
Size-Length | 9.2 mm |
Size-Width | 18.7 mm |
Size-Height | 7.25 mm |
Housing Color | Green |
Color | Green |
Contact Material | Copper Alloy |
Housing Material | Plastic |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536694040 |
ECCN Code | EAR99 |
