Description

The 1N5819G is an axial-leaded Schottky Barrier Rectifier with an epoxy molded case, all external surfaces corrosion-resistant and terminal lead is readily solderable finish. This series employs the Schottky barrier principle in a large area metal-to-silicon power diode. State-of-the-art geometry features chrome barrier metal, epitaxial construction with oxide passivation and metal overlap contact. It is ideally suited for use as rectifier in low-voltage, high-frequency inverter and freewheeling diodes.
Cathode indicated by polarity band
Extremely low forward voltage
Low stored charge and majority carrier conduction
Low power loss and high efficiency
48V Non-repetitive peak reverse voltage
28V RMS reverse voltage
80°C/W Junction-to-ambient thermal resistance
ESD sensitive device, take proper precaution while handling the device.

Show

1N5819G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-204AL
Voltage Rating (DC)	40.0 V
Current Rating	1.00 A
Halogen Free Status	Halogen Free
Output Current	≤1.00 A
Number of Positions	2 Position
Forward Voltage	600mV @1A
Polarity	Standard
Thermal Resistance	80℃/W (RθJA)
Max Breakdown Voltage	40 V
Forward Current	1 A
Max Forward Surge Current (Ifsm)	25 A
Maximum Forward Voltage (Max)	600 mV
Forward Current (Max)	1 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature (Max)	125 ℃
Power Dissipation (Max)	1250 mW
	Show
Size-Length	5.2 mm
Size-Width	2.7 mm
Size-Height	5.2 mm
Operating Temperature	-65℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
