ADG1221BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC153824
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG1221BRMZ Analog Switch, Dual Channel, SPST, 2Channels, 200Ω, 10.8V to 13.2V, ± 13.5V to ± 16.5V, MSOP
Stock Locations:
Availability:
226 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.77

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1221BRMZ is a single-pole single-throw (SPST) monolithic dual iCMOS® Analog Switch containing four independently selectable switches designed on an iCMOS (industrial CMOS) process. iCMOS is a modular manufacturing process combining high voltage CMOS and bipolar technologies. It enables the development of a wide range of high performance analog ICs, capable of 33V operation, in a footprint that no previous generation of high voltage parts has been able to achieve. Unlike analog ICs using conventional CMOS processes, iCMOS components can tolerate high supply voltages while providing increased performance, dramatically lower power consumption and reduced package size. The ultralow capacitance and exceptionally low charge injection of these switches make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch and fast settling are required.
No VL supply required
3V Logic-compatible inputs
Rail-to-rail operation
<0.5pC Charge injection over full signal range
2pF Off capacitance
20pA Off leakage

Show

ADG1221BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package (SI)	SOP
Case/Package	MSOP-10
Number of Outputs	2 Output
Supply Current	140 µA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	10 Position
Power Dissipation	2.90 mW
Bandwidth	960 MHz
Number of Inputs	2 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	960 MHz
Supply Voltage (Max)	16.5 V
Supply Voltage (Min)	16 V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
