Description

The 2STF2360 is a PNP fast-switching Power Transistor manufactured using new "PB-HDC" (power bipolar high density current) technology. The resulting transistor shows exceptional high gain performances coupled with very low saturation voltage.
Very low collector-emitter saturation voltage
High current gain characteristic
Fast-switching speed

Show

2STF2360 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-89-3
Frequency	130 MHz
Number of Positions	3 Position
Polarity	PNP
Power Dissipation	1.4 W
Gain Bandwidth Product	130 MHz
Breakdown Voltage (Collector to Emitter)	60 V
Continuous Collector Current	3A
hFE Min	160 @1A, 2V
Input Power (Max)	1.4 W
DC Current Gain (hFE)	160
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	1.4 W
	Show
Size-Length	4.6 mm
Size-Width	2.6 mm
Size-Height	1.6 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
