Image is for your reference only,please check specifications for details

AD203SN - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2270450
Category:
Amplifier, Buffer IC
Package:
PDIP-11
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD203SN Isolation Amplifier, Military Temperature Range, 1 Amplifier, 5mV, 1500Vrms, 12V to 16V, DIP
Stock Locations:
Availability:
289 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 390.61

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The AD203SN is designed and built expressly for use in hostile operating environments. The AD203SN is also an integral member of Analog Devices" AD200 Series of low cost, high performance, transformer coupled isolation amplifiers. Technological innovations in circuit design, transformer construction, surface mount components and assembly automation have resulted in a rugged, economical, military temperature range isolator that either retains or improves upon the key performance specifications of the AD202/AD204 line.
The AD203SN provides total galvanic isolation between the input and output stages of the isolation amplifier, including the power supplies, through the use of internal transformer coupling. The functionally complete design of the AD203SN, powered by a single + 15 V de supply, eliminates the need for an external de/de converter. This permits the designer to minimize the necessary circuit overhead and consequently reduce the overall design and component costs. Furthermore, the power consumption, nonlinearity and drift characteristics of transformer coupled devices are vastly superior to those achievable with other isolation technologies, without sacrificing bandwidth or noise performance. Finally, the AD203SN will maintain its high operating performance even under sustained common mode stress.
The design of the AD203SN emphasizes maximum flexibility and ease of use in a broad range of applications where signals must be measured or transmitted under high CMV conditions. The AD203SN has a ± 10 V output range, an uncommitted input amplifier, an output buffer, a 10 kHz full power bandwidth and a front-end isolated power supply of ± 15 V dc @ ± 5 mA.
**Applications**
Engine Monitoring and Control
Mobile Multichannel Data Acquisition Systems
Instrumentation and/or Control Signal Isolation
Current Shunt Measurements
High Voltage Instrumentation Amplifier
### Features and Benefits
Rugged Design: characterized to MIL-STD-883C
Environmental Test Methods
1004 (Moisture Resistance)
1010 Condition B (Temperature Cycling, -55°C to +125°C)
2002 Condition B (Mechanical Shock@ 1,500 g for 0.5 ms)
2004 (Lead Integrity)
2007 Condition A (Variable Frequency Vibration @20g)
2015 (Resistance to Solvents)
Reliable Design: Conforms to Stringent Quality and Reliability Standards
Characterized to the Full Military Temperature Range
-55°C to +125°C Rated Performance
10 kHz Full Power Bandwidth
Low Nonlinearity: ±0.025% max
Wide Output Range: ±10 V min (Into a 2.5 kΩ Load)
High CMV Isolation: 1500 V RMS Continuous
Isolated Power: ±15 V DC@ ±5 mA
Small Size: 2.23"x0.83"x0.65" 56.6 mmx21.1 mmx16.5 mm
Uncommitted Input Amplifier
Two-Port Isolation Through Transformer Coupling

Show

AD203SN Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	11 Pin
Case/Package	PDIP-11
Output Current	4mA @15V
Supply Current	20 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	106 dB
Bandwidth	10 kHz
Slew Rate	500 mV/μs
Gain Bandwidth Product	10 kHz
Isolation Voltage	1500 Vrms
Input Offset Voltage	5 mV
Input Bias Current	30 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	12V ~ 16V
Supply Voltage (Max)	16 V
Supply Voltage (Min)	12 V
	Show
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR
