AD5290YRMZ100 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC221240
Category:
Digital Potentiometer IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
AD5290YRMZ100, Digital Potentiometer 100K 256Position Serial-3 Wire, Serial-SPI 10Pin MSOP
Stock Locations:
Availability:
228 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 284.5

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5290YRMZ100 is a 256-position High Performance Compact Digital Potentiometer that can be used as a programmable resistor or resistor divider. It performs the same electronic adjustment function as mechanical potentiometers, variable resistors and trimmers, with enhanced resolution, solid-state reliability and superior temperature stability. With digital rather than manual control, the AD5290 provides layout flexibility and allows closed-loop dynamic controllability.
Low temperature coefficient
Midscale preset
iCMOS™ process technology
ESD sensitive device, take proper precaution while handling the device.

Show

AD5290YRMZ100 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Voltage (DC)	4.50V (min)
Capacitance Tolerance	±30 %
Supply Current	0.015 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	256 Position
Clock Speed	4.00MHz (max)
Resistance	100 kΩ
Resistance Tolerance	±30 %
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	30 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 125℃
Temperature Coefficient	±35 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
