AD8330ARQZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC368604
Category:
Amplifier, Buffer IC
Package:
QSOP-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8330ARQZ Programmable/Variable Amplifier, 1Channels, 1 Amplifier, 150MHz, -40℃, 85℃, 2.7V to 6V
Stock Locations:
Availability:
90 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.52

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8330ARQZ is a Wideband Variable Gain Amplifier for applications requiring a fully differential signal path, low noise, well-defined gain and moderately low distortion from DC to 150MHz. The input pins can also be driven from a single-ended source. The output pins can drive single-sided loads essentially rail-to-rail. The differential output resistance is 150R. The basic gain function is linear-in-dB, controlled by the voltage applied to Pin VDBS. The gain ranges from 0 to 50dB for control voltages between 0 and 1.5V, a slope of 30mV/dB. By changing the logic level on Pin MODE, the gain decreases over the same range, with an opposite slope. A second gain control port is provided at the VMAG pin and allows the user to vary the numeric gain from a factor of 0.03 to 10. Using VMAG, the basic 0 to 50dB range can be repositioned to any value from 20dB higher to at least 30dB lower to suit the application, thereby providing an unprecedented gain range of over 100dB.
Fully differential signal path, also used with single-sided signals
Automatic offset compensation (optional)
Linear-in-dB and linear-in-magnitude gain modes
50dB to 0dB at -30mV/dB Inverted gain mode
Constant bandwidth
5nV/√Hz Typical noise at maximum gain
* Low power
ESD sensitive device, take proper precaution while handling the device.

Show

AD8330ARQZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	QSOP-16
Supply Voltage (DC)	6.00 V
Supply Current	20 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	16 Position
Power Dissipation	620 mW
Common Mode Rejection Ratio	55 dB
Rise Time	2 ns
Bandwidth	150 MHz
Slew Rate	1.50 kV/μs
Gain Bandwidth Product	150 MHz
Gain	50.0 dB
Input Offset Voltage	1 mV
Input Bias Current	100 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	150 MHz
Gain Bandwidth	150 MHz
Power Dissipation (Max)	620 mW
Minimum CMRR Range	55 dB
Supply Voltage	2.7V ~ 6V
Supply Voltage (Max)	5V ~ 7V
Input Voltage	0.45V ~ 5V
	Show
Size-Length	5 mm
Size-Width	3.91 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
