Description

The AD534LD is a quadrant monolithic laser/internally-trimmed precision IC Multiplier for differential ratio and percentage computations, algebraic and trigonometric function synthesis. A maximum multiplication error of ±0.25% is guaranteed for the AD534L without any external trimming. Excellent supply rejection, low temperature coefficients and long-term stability of the on-chip thin film resistors and buried Zener reference preserve accuracy even under adverse conditions of use. It is the first multiplier to offer fully differential, high impedance operation on all inputs, including the Z input, a feature that greatly increases its flexibility and ease of use. The scale factor is pre trimmed to the standard value of 10.00V by means of an external resistor, this can be reduced to values as low as 3V.
Pre-trimmed to ±0.25% maximum 4-quadrant error
Scale factor adjustable to provide up to x100 gain
Excellent long-term stability
90µVRMS at 10Hz to10kHz Low noise design

Show

AD534LD Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	CDIP-14
Supply Voltage (DC)	8.00V (min)
Output Voltage	11.0 V
Supply Current	6.00 mA
Number of Bits	4 Bit
Power Dissipation	500 mW
Slew Rate	20.0 V/μs
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage (Max)	18 V
Supply Voltage (Min)	8 V
	Show
Size-Height	3.56 mm
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
