Image is for your reference only,please check specifications for details

AD5420 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC134066493
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
Single-Channel, 12-/16Bit, Serial Input, 4mA to 20mA, Current Source DAC
Stock Locations:
Availability:
270 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The AD5410/AD5420 are low cost, precision, fully integrated 12-/16-bit converters offering a programmable current source output designed to meet the requirements of industrial process control applications. The output current range is programmable at 4 mA to 20 mA, 0 mA to 20 mA, or an overrange function of 0 mA to 24 mA. The output is open-circuit protected. The device operates with a power supply (AVDD) range from 10.8 V to 60 V. Output loop compliance is 0 V to AVDD − 2.5 V.
The flexible serial interface is SPI, MICROWIRE™, QSPI™, and DSP compatible and can be operated in 3-wire mode to mini mize the digital isolation required in isolated applications. The device also includes a power-on reset function, ensuring that the device powers up in a known state, and an asynchronous CLEAR pin that sets the output to the low end of the selected current range.
The total unadjusted error is typically ±0.01% FSR.
FEATURES
12-/16-bit resolution and monotonicity
Current output ranges: 4 mA to 20 mA, 0 mA to 20 mA, or
0 mA to 24 mA
±0.01% FSR typical total unadjusted error (TUE)
±3 ppm/°C typical output drift
Flexible serial digital interface
On-chip output fault detection
On-chip reference (10 ppm/°C maximum)
Feedback/monitoring of output current
Asynchronous clear function
Power supply (AVDD) range
10.8 V to 40 V; AD5410AREZ/AD5420AREZ
10.8 V to 60 V; AD5410ACPZ/AD5420ACPZ
Output loop compliance to AVDD − 2.5 V
Temperature range: −40°C to +85°C
24-lead TSSOP and 40-lead LFCSP packages
APPLICATIONS
Process control
Actuator control
PLC
HART network connectivity

Show

AD5420 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
	Show
Product Lifecycle Status	Active
RoHS	RoHS Compliant
