AD592CNZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC294556
Category:
Temperature Sensor
Package:
TO-92-3
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD592CNZ Temperature Sensor IC, Current, ± 0.3℃, -25℃, +105℃, TO-92, 3Pins
Stock Locations:
Availability:
824 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 96.09

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD592CNZ is a 2-terminal Monolithic IC Temperature Transducer that provides an output current proportional to absolute temperature. For a wide range of supply voltages the transducer acts as a high impedance temperature dependent current source of 1µA/K. Improved design and laser wafer trimming of the IC"s thin film resistors allows the AD592 to achieve absolute accuracy levels and nonlinearity errors previously unattainable at a comparable price. The inherent low cost of a monolithic integrated circuit combined with a low total parts count in any given application.
High pre-calibrated accuracy
Excellent linearity
Single supply operation
Excellent repeatability and stability
High level output
Minimal self-heating errors

Show

AD592CNZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-92-3
Supply Voltage (DC)	4.00V (min)
Output Current	298 µA
Number of Positions	3 Position
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-25 ℃
Accuracy	±0.5℃ (Max)
Supply Voltage	4V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	4 V
	Show
Size-Length	5.21 mm
Size-Width	4.19 mm
Size-Height	4.83 mm
Operating Temperature	-25℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR
