AD630JNZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC979343
Category:
RF Module, IC, Accessory
Package:
PDIP-20
Datasheet:
Datasheet 3D Model
Description:
RF Modulation / Demodulation IC, 2MHz Bandwidth, 100dB Noise, 5V to 16.5V supply, DIP-20
Stock Locations:
Availability:
496 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 61.51

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD630JNZ is a High Precision Balanced Modulator/Demodulator that combines a flexible commutating architecture with the accuracy and temperature stability afforded by laser wafer trimmed thin film resistors. The AD630 can be thought of as a precision operational amplifier with two independent differential input stages and a precision comparator that is used to select the active front end. The rapid response time of this comparator coupled with the high slew rate and fast settling of the linear amplifiers minimize switching distortion. It used in precision signal processing and instrumentation applications that require wide dynamic range. When used as a synchronous demodulator in a lock-in amplifier configuration, the AD630 can recover a small signal from 100dB of interfering noise (see the Lock-In Amplifier Applications section). Although optimized for operation up to 1kHz, the circuit is useful at frequencies up to several hundred kilohertz.
Recovers signal from 100dB noise
2MHz Channel bandwidth
45V/µs Slew rate
Low crosstalk
Pin programmable, closed-loop gains of ±1 and ±2
0.05% Closed-loop gain accuracy and match
100µV Channel offset voltage
350kHz Full power bandwidth
