Image is for your reference only,please check specifications for details

AD637AQ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC944437
Category:
Power Supply Accessory
Package:
CDIP-14
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD637AQ RMS to DC Converter, 0.5%, 8MHz, -40℃, 85℃, DIP, 14Pins
Stock Locations:
Availability:
237 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 80.43

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Converting RMS to DC voltage with high accuracy is easy with this AD637AQ RMS to DC converter by Analog Devices. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This RMS to DC converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.

Show

AD637AQ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	CDIP-14
Output Current	6 mA
Supply Current	2.2 mA
Power Dissipation	108 mW
Bandwidth	8 MHz
Input Voltage (Max)	7 V
Input Voltage (Min)	0 V
Output Voltage (Max)	13.5 V
Output Current (Max)	6 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	8000 kHz
Power Dissipation (Max)	108 mW
Accuracy	0.5 %
Input Voltage	0V ~ 7V
	Show
Size-Length	19.94 mm
Size-Width	7.87 mm
Size-Height	3.56 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
