- AD7609BSTZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC415600
-
Category:Analog to Digital, ADC IC
-
Package:LQFP-64
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES AD7609BSTZ Analog to Digital Converter, 18Bit, 250KSPS, Single, 4.75V, 5.25V, LQFP
-
Stock Locations:
-
Availability:2,310 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 55.69
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The AD7609BSTZ is a 8-channel Differential Data Acquisition System (DAS) with 18-bit bipolar input simultaneous sampling analogue to digital converter (ADC). The part contains analogue input clamp protection, a second-order anti-aliasing filter, a track-and-hold amplifier, an 18-bit charge redistribution successive approximation ADC, a flexible digital filter, a 2.5V reference and reference buffer and high speed serial and parallel interfaces. It operates from a single 5V supply and can accommodate ±10V and ±5V true bipolar input signals while sampling at throughput rates up to 200kSPS for all channels. The input clamp protection circuitry can tolerate voltages up to ±16.5V. The AD7606 has 1MR analogue input impedance regardless of sampling frequency. The single supply operation, on-chip filtering and high input impedance eliminate the need for driver operational amplifiers and external bipolar supplies.
- 8 Simultaneously sampled inputs
- True differential inputs
- Fully integrated data acquisition solution
- Analogue input clamp protection
- Input buffer with 1MR analogue input impedance
- Second-order anti-aliasing analogue filter
- On-chip accurate reference and reference buffer
- Flexible parallel/serial interface
- Low power
- ESD sensitive device, take proper precaution while handling the device.
AD7609BSTZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 64 Pin |
| Case/Package | LQFP-64 |
| Supply Voltage (DC) | 4.75V (min) |
| Supply Current | 20.0 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 8 Channel |
| Number of Positions | 64 Position |
| Number of Bits | 18 Bit |
| Power Dissipation | 100 mW |
| Sample Rate | 200 ksps |
| Power Consumption | 100 mW |
| Resolution (Bits) | 18.0 Bit |
| Number of ADCs | 1 ADC |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 157 mW |
| Number of Input Channels | 8 Channel |
| Supply Voltage (Max) | 5.25 V |
| Supply Voltage (Min) | 4.75 V |
| Show | |
| Size-Length | 10.2 mm |
| Size-Width | 10.2 mm |
| Size-Height | 1.45 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| Mil-Spec | No |
| REACH SVHC Compliance Edition | 2015/12/17 |
