AD811JRZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC305396
Category:
Video Amplifier, CATV Amplifier IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD811JRZ Video Amplifier, 1 Amplifiers, 140MHz, 2500V/µs, 0 °C, 70℃, 100mA
Stock Locations:
Availability:
247 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.43

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD811JRZ is a High Performance Video Operational Amplifier optimized for broadcast-quality video systems. The -3dB bandwidth of 120MHz at a gain of +2 and the differential gain and phase of 0.01% and 0.01° (RL = 150R) make it an excellent choice for all video systems. The AD811 is designed to meet a stringent 0.1dB gain flatness specification to a bandwidth of 35MHz (G = +2) in addition to low differential gain and phase errors. This performance is achieved whether driving one or two back-terminated 75R cables, with a low power supply current of 16.5mA. The op amp is specified over a power supply range of ±4.5 to ±18V. It is also excellent for pulsed applications where transient response is critical. It can achieve a maximum slew rate of greater than 2500V/µs with a settling time of less than 25ns to 0.1% on a 2V step and 65ns to 0.01% on a 10V step.
High speed
25ns Settling time to 0.1% (for a 2V step)
65ns Settling time to 0.01% (for a 10V step)
Excellent video performance (RL = 150R)
0.01% Differential gain
0.01° Differential phase
1.9nV/√Hz Voltage noise
Low distortion
-74dB at 10MHz THD
Flexible operation
3mV Maximum input offset voltage
