ADG884BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC461271
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG884BRMZ Analog Switch, Dual Channel, SPDT, 2Channels, 0.37Ω, 1.8V to 5.5V, MSOP, 10Pins
Stock Locations:
Availability:
261 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG884BRMZ is a CMOS Dual 2:1 MUX/SPDT Audio Switch that offers ultralow on resistance of 0.41R over the full temperature range, making the part an ideal solution for applications that require minimal distortion through the switch. It also has the capability of carrying large amounts of current, typically 600mA at 5V operation. When on, each switch conducts equally well in both directions and has an input signal range that extends to the supplies. The ADG884 exhibits break-before-make switching action. This is ideal to use in MP3 players, power routing, PCMCIA cards and cellular phones as well as audio and video signal routing.
Ultralow on-resistance
Excellent audio performance, ultralow distortion
High current carrying capability
Rail-to-rail operation
Typical power consumption (<0.1µW)
ESD sensitive device, take proper precaution while handling the device.

Show

ADG884BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Voltage (DC)	5.50V (max)
Number of Outputs	4 Output
Contacts Type	SPDT
Supply Current	3 nA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	10 Position
Drain to Source Resistance (on) (Rds)	280 mΩ
Number of Bits	2 Bit
Power Dissipation	5.50 µW
Bandwidth	18 MHz
Number of Inputs	2 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	18 MHz
Supply Voltage	1.8V ~ 5.5V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
