Description
- Think of Analog Devices" differential adc driver AD8138AR differential amplifier the next time you are receiving unwanted sound distortion within your project. Its maximum power dissipation is 550 mW. It has a differential output. Its typical dual supply voltage is ±3|±5 V, with a minimum of ±1.4 V and maximum of ±5.5 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device uses one or two power supplies. It has a single channel per chip.
AD8138AR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Output Current | 95mA @5V |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Power Dissipation | 0.55 W |
| Common Mode Rejection Ratio | 77 dB |
| Input Capacitance | 1.00 pF |
| Slew Rate | 1.15 kV/μs |
| Gain Bandwidth Product | 320 MHz |
| Input Offset Voltage | 2.5 mV |
| Input Bias Current | 7000 nA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 550 mW |
| Minimum CMRR Range | 60dB ~ 75dB |
| Supply Voltage | 2.7V ~ 11V |
| Supply Voltage (Max) | 11 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | End of Life |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| HK STC License | NLR |
