AD8213YRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC291193
Category:
Amplifier, Buffer IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8213YRMZ Current Sense Amplifier, Dual, 2 Amplifier, 0.0025A, MSOP, 10Pins, -40℃, 125℃
Stock Locations:
Availability:
216 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8213YRMZ is a dual-channel precision Current Sense Amplifier features a set gain of 20V/V, with a maximum ±0.5% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. Excellent common-mode rejection from -2 to +65V, is independent of the 5V supply. Special circuitry is devoted to output linearity being maintained throughout the input differential voltage range of 0 mV to 250mV, regardless of the common-mode voltage present. The AD8213 also features additional pins that allow the user to low-pass filter the input signal before amplifying, via an external capacitor to ground.
Buffered output voltage
Excellent AC and DC performance
Indefinite output short-circuit duration
±4000V HBM ESD rating
-0.3V Reverse supply voltage

Show

AD8213YRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Voltage (DC)	4.50V (min)
Output Voltage	4.95 V
Supply Current	2.50 mA
Number of Circuits	1 Circuit
Number of Channels	2 Channel
Number of Positions	10 Position
Common Mode Rejection Ratio	120 dB
Bandwidth	500 kHz
Slew Rate	4.50 V/μs
Input Offset Voltage	1 mV
Input Bias Current	2.5 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±0.25 %
Minimum CMRR Range	80 dB
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	3.1 mm
Size-Width	3.1 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
